Product Description
“EPDM” sheet rubber is a versatile blended sheet composed of Ethylene Propylene Diene Monomer and Styrene Butadiene Rubber. It achieves an ideal balance to create an all-purpose, weather resistant rubber. For this reason, EPDM material is an excellent medium for outdoor uses. Furthermore, other benefits include great pliability and elasticity. It is easy to see that EPDM rubber is the premier outdoor rubber!
Excellent Chemical and Weather Resistance: The special properties of EPDM sheet rubber allow it to withstand chemicals in addition to weather-related hazards such as UV rays and ozone. As a weather resistant rubber, this EPDM sheet rubber is commonly used in industrial applications and machinery that are exposed to the elements. Damage from rainstorms, pollution, and the sun will occur at a slower rate compared to a fully exposed EPDM rubber when compared to other elastomers like SBR, Nitrile or Neoprene.
Excellent Industrial Sheet Rubber: EPDM rubber has adequate elastic and pliable qualities. The material has a durometer of Shore 55-65A but on average, has a Shore 60A measurement. A Shore A scale measures the hardness of the rubber. For example, a soft pencil eraser has a durometer of Shore 20A. Although higher than an eraser, the durometer of EPDM still maintains a good amount of flexibility for all of your necessary projects. In addition, EPDM rubber has a minimum elongation of 300%.
Popular Gauges: Rubber-Cal understands that some gauges are in higher demand than others. Therefore, the most popular gauges can usually be found in stock, ready for customers. This includes a range of eight different gauges to choose from. Custom thickness and widths are available upon request, though non-standard sizes will have large minimum orders. A Rubber-Cal representative can assist you in exploring customization options. With so many choices, you’re bound to find the perfect size of EPDM material.
Other Benefits:
- EPDM rubber with a smooth finish
- A black weather resistant rubber that is ideal as an outdoor liner or pad
- EPDM material is in stock in 1/16″, 1/8″, 3/16″, 1/4″, 3/8″, 1/2″ thickness
- A blend of Ethylene Propylene Diene Monomer (EPDM rubber) and SBR
- This sheet rubber weighs about 1-1/4 lbs. per square foot in 1/8″ thickness
Company Reviews
Product Specifications
| Description: | Ethylene Propylene Diene Monomer (EPDM) and SBR blended sheet is a black colored sheet rubber which provides very good resistance to weathering, ozone and UV exposure. |
| Compound: | 10% Ethylene Propylene Diene Monomer (EPDM) Base, SBR |
| Color: | Black |
| Weight: | Approximate weight per square foot: 1/8″ weighs 1-1/4 lbs. |
| Durometer: | 60 Shore A, +/- 5 |
| Temperature Range: | -40 F to 212 F |
| Minimum Tensile: | 725 PSI or 5 MPA |
| Finish: | Smooth |
| Minimum Elongation: | 300% |
| Gauges: | 1/32”, 1/16″, 3/32”, 1/8″, 3/16″, 1/4″, 3/8″, 1/2″, 3/4” (custom gauges up to 2” thick are available upon request) |
| Widths: | 36″ (custom widths up to 78” are available upon request) |
| Roll Length: | 25′ or 50′ depending on thickness. |
| PSA: | Pressure sensitive adhesive can be applied to this product upon request. |
| Chemical Resistance: | Good resistance to UV rays and ozone. Good resistance to Anti-freeze, Synthetic Detergents, Acetone, Boric acid, Ethanol, Formaldehyde, Mercury, Potassium Sulfate, Silver Nitrate, Steam (up to 212 Fahrenheit), Saccharin. For EPDM Blend’s compatibility with your specific medium please consult a Rubber-Cal representative. |
| Applications: | Provides outstanding resistance to weathering, ozone and UV exposure. Gasket, bumper and general exterior applications. |
| Flexibility: | This medium durometer (55-65) sheet rubber offers good pliability and elasticity. |
| Custom Cuts | In addition to hand fabrication, this product can be fabricated using laser, die, and water-jet cut. Please submit your drawings for a price quote. |
| Availability: | Popular gauges are generally in stock. |
