WARNING: Cancer and Reproductive Harm - Volume Pricing
| Thickness | Width | Weight per Roll | Weight per Linear ft | 5-24 Feet | 25-99 Feet | 100-499 Feet | 500+ Feet |
| 1/16″ or 1.6mm | 36″ or 91.4 cm | 84 lbs | 1.7 lbs | $7.40 | $5.38 | $4.71 | $3.29 |
| 3/32″ or 2.4mm | 36″ or 91.4 cm | 126 lbs | 2.5 lbs | $11.09 | $8.07 | $7.06 | $4.93 |
| 1/8″ or 3.2mm | 36″ or 91.4 cm | 167 lbs | 3.3 lbs | $14.79 | $10.76 | $9.41 | $6.58 |
| 3/16″ or 4.8mm | 36″ or 91.4 cm | 250 lbs | 5.0 lbs | $22.19 | $16.13 | $14.12 | $9.86 |
| 1/4″ or 6.4mm | 36″ or 91.4 cm | 333 lbs | 6.7 lbs | $29.58 | $21.51 | $18.82 | $13.15 |
Product Description
Red sheet rubber is a blend of natural rubber and styrene butadiene rubber (SBR). Able to endure physically abrasive conditions, this rubber roll material is overall harder and denser thanks to the SBR used in it. This is also a waterproof rubber sheet as it can be used in applications involving hot and cold water. However, it is not recommended for applications that may involve excessive oils or outdoor weather conditions. It is mostly meant to physical industrial applications. The main attraction of these hard rubber sheets is their red color. Some consumers take aesthetic value into consideration for their projects, and we aim to offer rubber roll material that is excellent both in a functional sense as well as an aesthetic sense. Keep in mind this product does have slight color variations from roll to roll.
Strong Rubber Material: With a high durometer rating of 60-70, this red sheet rubber material is well suited to performing in industrial applications that may be physically abrasive. It is meant to be used wherever a sturdy bumper or gasket is required. These hard rubber sheets are only moderately flexible, but they make up for this with their increased resistance to physical indentation. They are good at keeping their form, giving them a longer life for whatever application they may be used in. The styrene butadiene rubber used in this rubber sheet’s construction contributes to its superior durability.
Aesthetic Appeal: Sometimes the physical aesthetics of a product matter a lot. A particular job may call for a particular color from a component. This is why we offer this rubber roll material in red. It comes in a color variation that ranges from a darker red to a lighter red. It is simply meant to enhance the visual appeal of wherever it is used.
Waterproof Rubber Sheet: Our red sheet rubber is excellent for general gasket material that will come into contact with hot or cold water. This is partly thanks to the mix of natural rubber and styrene butadiene rubber used to make these hard rubber sheets. Rubber by itself is a fairly water resistant material. It inhibits the growth of any organic byproducts that may form as the result of excess moisture. This blended material gives your project even greater resistance to the harms posed by water.
More Benefits:
- A popular gasket material
- Available for custom fabrication
- A more cost-effective sheet rubber
- Works well in temperatures between -10° F and 195° F
- Is able to resist anti-freeze, salts, bases, and some alcohols
- Features a moderate degree of oil and ozone resistance
Company Reviews
Product Specifications
| Description: | Red Sheet is an excellent general-purpose gasket material for air, hot and cold water, saturated steam and exterior service. |
| Compound: | Blend of SBR (Styrene Butadiene Rubber) and Natural Rubbers. |
| Color: | Red |
| Weight: | Approximate weight per square foot: 1/8″ weighs 1-1/4 lbs. |
| Durometer: | 65 Shore A, +/- 5 |
| Temperature Range: | -10 F to 195 F |
| Minimum Tensile: | 435 PSI, 3 MPA |
| Finish: | Smooth |
| Minimum Elongation: | 300% |
| Gauges: | 1/16″, 1/8″, 3/16″, 1/4″ (custom gauges up to 2” thick are available upon request) |
| Widths: | 36″ or 48″ (custom widths up to 78” are available upon request) |
| Roll Length: | 50′ |
| PSA: | Pressure sensitive adhesive can be applied to this product upon request. |
| Chemical Resistance: | Water, Air, Anti-Freeze, Detergents, Salt Solutions, Bases, Alcohols, and some Acids. It also has a moderate oil and ozone resistance. For Red Sheet Rubber’s compatibility with your specific medium please consult a Rubber-Cal representative. |
| Applications: | Assembly Line Gasketing, Abrasion Resistant Applications, Construction Sites, Cost Conscious Applications, General purpose flapping. |
| Flexibility: | This fairly hard durometer (65-75) sheet rubber offers moderate flexibility and minimal elasticity. |
| Custom Cuts | In addition to hand fabrication, this product can be fabricated using laser, die, and water-jet cut. Please submit your drawings for a price quote. |
| Availability: | Popular gauges are always in stock. |
