WARNING: Cancer and Reproductive Harm - Volume Pricing
| Thickness | Width | Weight per Roll | Weight per Linear ft | 5-24 Feet | 25-99 Feet | 100-499 Feet | 500+ Feet |
| 1/32″ or 0.8mm | 36″ or 91.4 cm | 42 lbs | .8 lbs | $15.67 | $11.75 | $9.79 | $7.83 |
| 1/16″ or 1.6mm | 36″ or 91.4 cm | 83 lbs | 1.7 lbs | $25.07 | $18.80 | $15.67 | $12.54 |
| 3/32″ or 2.4mm | 36″ or 91.4 cm | 125 lbs | 2.5 lbs | N/A | N/A | $21.35 | $17.08 |
| 1/8″ or 3.2mm | 36″ or 91.4 cm | 167 lbs | 3.3 lbs | $44.03 | $33.02 | $27.52 | $22.01 |
| 3/16″ or 4.8mm | 36″ or 91.4 cm | 250 lbs | 5.0 lbs | N/A | N/A | $41.28 | $33.02 |
| 1/4″ or 6.4mm | 36″ or 91.4 cm | 333 lbs | 6.7 lbs | N/A | N/A | $55.04 | $44.03 |
Product Description
This black colored silicone rubber is a Premium Grade version that is meant for use where working temperatures are extreme. The unique feature about this version is that it is black silicone, suited for use as parts in applications that require dark colored parts that give the project a professional aesthetic appeal. These silicone sheets perform very well in both high and low temperature extremes. This premium level high temperature silicone also features a very strong resistance to chemicals.
Survives in Extreme Temperatures: Over the years since its initial discovery, silicone rubber has been used in various applications that require seals and gaskets to be exposed to harsh temperatures. Silicone seals that are made from the Premium Grade version can handle more extreme temperatures than their standard level counterparts. The highest temperature that this black silicone material can handle is 500° F. On the opposite side of the spectrum, the lowest temperature that it can endure is -103° F.
Superior Chemical Resistance: Although it can withstand conditions of a high temperature, silicone also features a level of chemical resistance that is highly desirable. The Premium Grade silicone sheets can resist chemicals such as ammonia gas, lime sulfur, sodium sulfate, tartaric acid, and more. Silicone rubber combines its temperature resistance with its chemical properties to resist the degrading effects of chemicals that come in varying degrees. This is a primary reason why silicone seals and gaskets are popular for use in laboratory equipment.
Smooth Black Finish: In terms of physical appearance, this high temperature silicone material is straightforward and professional. Its surface texture is smooth and black in color. Black silicone can be used for a range of different types of applications. A black hued component will not distract or take away from the overall integrity of the application it is used for. As an added bonus, the smooth texture of these silicone sheets allows them to be used in more applications without any hindrances.
More Benefits:
- Great working temperature range between -103° F and 500° F
- All black silicone provides for a straightforward professional aesthetic
- A premium high temperature silicone that can be resist ozone and UV rays
- Silicone rubber conforming to ZZR-765 Cl 2A & 2B Gr 60, AMS3302, ASTM D2000.
- Various different customization options for these silicone seals are available upon request
Company Reviews
Product Specifications
| Description: | Specification or Premium Grade Silicone sheeting is used in applications where higher physical properties are required. It is resistant to both high and low temperature extremes, and is commonly used for gasketing solutions in harsh environments. |
| Compound: | Silicone conforming to ZZR-765 C1 2A & 2B Gr 60, AMS3303, ASTM D2000. |
| Color: | Black |
| Durometer: | 60A +/- 5 is stocked. |
| Temperature Range: | -103 F to 500 F |
| Minimum Tensile: | 870 PSI or 6 MPA |
| Finish: | Smooth |
| Minimum Elongation: | 400% |
| Gauges: | 1/32”, 1/16”, 1/8” – in stock 3/32”, 3/16”, 1/4”, 3/8”, 1/2” and other custom gauges available upon request |
| Widths: | 36″ (custom widths up to 60″ available upon request) |
| Chemical Resistance: | Excellent resistance to UV/Ozone, Acetic Acid, Ammonia Gas (hot and cold), Corn Oil, Fish Oil, Lime Sulfur, Methyl Ether, Ozone, Sodium Sulfate, Tartaric Acid, Vinegar, and many more. |
| Application | High-Temperature Gasketing, Laboratory Equipment, Chemical Resistance, Low Compression Materials. |
| Flexibility: | This elastomer is available in a wide range of durometers, from soft to hard (35 to 75 shore A), satisfying most commercial needs. |
| Custom Cuts: | In addition to hand fabrication, this product can be fabricated using laser, die, and water-jet cutting. Please submit your drawings for a price quote. |
| Availability | Popular Gauges are Stocked. |
