WARNING: Cancer and Reproductive Harm - Volume Pricing
| Thickness | Width | Weight per Roll | Weight per Linear ft | 5-24 Feet | 25-99 Feet | 100-499 Feet | 500+ Feet |
| 1/32″ or 0.8mm | 36″ or 91.4 cm | 42 lbs | .8 lbs | $15.67 | $11.75 | $9.79 | $7.83 |
| 1/16″ or 1.6mm | 36″ or 91.4 cm | 83 lbs | 1.7 lbs | $25.07 | $18.80 | $15.67 | $12.54 |
| 3/32″ or 2.4mm | 36″ or 91.4 cm | 125 lbs | 2.5 lbs | N/A | N/A | $21.35 | $17.08 |
| 1/8″ or 3.2mm | 36″ or 91.4 cm | 167 lbs | 3.3 lbs | $44.03 | $33.02 | $27.52 | $22.01 |
| 3/16″ or 4.8mm | 36″ or 91.4 cm | 250 lbs | 5.0 lbs | N/A | N/A | $41.28 | $33.02 |
| 1/4″ or 6.4mm | 36″ or 91.4 cm | 333 lbs | 6.7 lbs | N/A | N/A | $55.04 | $44.03 |
Product Description
Premium Grade Gray silicone rubber is recommended for use in applications where higher physical properties are required. It is ideal for use as seal and gasket material in harsh environments that involve very high or very low temperatures. This heat resistant rubber also features strong resistance to chemicals. We make it a point to offer this superior silicone material in custom lengths and widths that suit your specific requirements. This gray version of silicone sheeting is stocked in several popular gauges and widths.
Heat Resistant Rubber: Silicone is an elastomer that is best used for temperature intensive applications. It can function excellently in temperatures as high as 500° F. Silicone rubber is comfortable in extremely hot situations that would cause failure in most other types of rubber. This material is ideal for use as high temperature gasket material in heavy industrial settings. On the flip side, it can also endure extreme cold. The lowest temperature point that it can endure is -103° F.
Custom Options: Our gray premium silicone sheeting is available in custom specified options. If you need rolls of a premium grade sheet in specific sizes so as to not have any waste leftover, you can order the material in specific widths, lengths, and thicknesses. Additionally, we allow for more aesthetic options by offering this silicone rubber in three different color options: red, black, and gray.
High and Low Durometers: This chemical resistant silicone is available to consumers in several different durometer categories. The first is the very soft durometer of 40, meaning that the silicone material is very elastic and suitable for tasks that need very pliable rubber parts, but it is not the best in terms of physical durability. The next durometer grade is 50, offering a better level of resistance to physical stress but still flexible enough to be used in numerous light to medium level applications. 60 durometer silicone rubber offers more physical durability, but reduced elasticity. Silicone sheeting that had a durometer rating of 70 is very physically durable and ideal for applications that demand tough parts. However, it sacrifices elasticity in exchange for its increased strength. No matter what your application demands from out heat resistant rubber, we have the right premium grade silicone for your task.
More Benefits:
- Conforms to ZZR-765 C1 2A & 2B Gr 60, AMS3302,
- Vast temperature range between -103° F and 500° F
- Excellent resistance to outdoor conditions like UV rays and ozone
- Chemical resistant silicone that can resist a variety of chemicals
- Silicone material that is ideal for gasket applications that involve harsh conditions, either physically or elementally
Company Reviews
Product Specifications
| Description: | Specification or Premium Grade Silicone sheeting is used in applications where higher physical properties are required. It is resistant to both high and low temperature extremes, and is commonly used for gasketing solutions in harsh environments. |
| Compound: | Silicone conforming to ZZR-765 C1 2A & 2B Gr 60, AMS3303, ASTM D2000. |
| Color: | Gray |
| Durometer: | 60A +/- 5 is stocked. |
| Temperature Range: | -103 F to 500 F |
| Minimum Tensile: | 870 PSI or 6 MPA |
| Finish: | Smooth |
| Minimum Elongation: | 400% |
| Gauges: | 1/32”, 1/16”, 1/8” – in stock 3/32”, 3/16”, 1/4”, 3/8”, 1/2” and other custom gauges available upon request |
| Widths: | 36″ (custom widths up to 60″ available upon request) |
| Chemical Resistance: | Excellent resistance to UV/Ozone, Acetic Acid, Ammonia Gas (hot and cold), Corn Oil, Fish Oil, Lime Sulfur, Methyl Ether, Ozone, Sodium Sulfate, Tartaric Acid, Vinegar, and many more. |
| Application | High-Temperature Gasketing, Laboratory Equipment, Chemical Resistance, Low Compression Materials. |
| Flexibility: | This elastomer is available in a wide range of durometers, from soft to hard (35 to 75 shore A), satisfying most commercial needs. |
| Custom Cuts: | In addition to hand fabrication, this product can be fabricated using laser, die, and water-jet cutting. Please submit your drawings for a price quote. |
| Availability | Popular Gauges are Stocked. |
